DESCRIPTION

The body of the Primus fitting is made entirely of AISI316 stainless steel. The stainless steel used is the preferred material in medical facilities, gastronomy and food processing, because there are particularly high demands on hygiene. The germ resistance of stainless steel has already been confirmed several times in scientific studies.

Low germ load and easy maintenance of the fitting

The stainless steel prevents the surfaces of the fittings from being contaminated with germs in various ways. The particularly smooth surface makes it difficult for germs to settle and grow. In addition, the stainless steel is particularly easy and thorough to clean. The surface structure is so firm that cleaning and disinfection cannot harm it. The ions in the surface also have an antibacterial effect.

Elegant and timeless design

The Primus faucet impresses with its elegant, narrow body and the fact that the water flow is activated without contact when you hold your hands under the spout.

The water flow stops when you remove your hands. This saves water and protects you from cross-contamination.

You can easily set the water temperature using the optionally available thermostatic premixer. To round off the washing experience, there is also a matching Primus stainless steel soap dispenser.

CHARACTERISTICS

Touch-free electronic basin valve. For cold or premixed water. Power supply by 9v battery or 9v power supply possible. Body in stainless steel AISI316 (brushed). Activated by an IR sensor integrated in the spout. Significantly reduces water consumption and protects against cross-contamination. The sensor settings can be adjusted using an optional remote control.

OPERATION

The faucet is activated automatically as soon as the user puts his hand in the sensor area and stops when the user removes his hand again.

USE

Combines an elegant design with vandal-proof properties. Easy installation and durable even in the harshest installation environments. Saves water, maintains cleanliness and protects against cross-contamination. Ideal for offices, hotels and restaurants.

POWER SUPPLY

  • 9V plug-in power supply 100 – 240 V 50 – 60 HZ
  • Battery box for 1 x 9V battery

FLOW PRESSURE

0.5-8.0 bar (7-116 PSI), with an operating pressure
over 8 bar, use a pressure reducing valve

WATER SUPPLY

Cold or premixed water

WATER SAVING OPTIONS

6 l/min/1.58 GPM;
4 l/min/1 GPM;
3 l/min/0.8 GPM;
1.89 l/min/0.5 GPM;
1.3 l/min/0.35 GPM

WATER TEMP

Max. 70°C (158°F)

SAFETY SHUTDOWN

90 seconds, can be adjusted via remote control

HYGIENE FLUSHING

24 hours after the last use, for 30 seconds, Adjustability 12-72 hours

SENSOR ACTIVATION

Preset sensor range 120mm, adjustable with the optional remote control

Primus soap dispenser

PPrimus stainless steel soap dispenser

The body of the Primus soap dispenser is made entirely of AISI316 stainless steel. The stainless steel used is the preferred material in medical facilities, catering and food processing when there are particularly high demands on hygiene. The germ resistance of stainless steel has already been confirmed several times in scientific studies.

Low germ load and easy maintenance of the soap dispenser

The stainless steel prevents the surfaces of the soap dispenser from being contaminated by germs in various ways. The particularly smooth surface makes it difficult for germs to accumulate. The stainless steel can be cleaned particularly thoroughly and easily. The surface structure is so firm that cleaning and disinfection cannot harm it. The ions in the surface also have an antibacterial effect.

Elegant design combined with innovative usability

The Primus soap dispenser impresses with its elegant, narrow body. By moving the hands in front of the soap dispenser, an individually adjustable amount of soap is provided. The soap tank can easily be filled with various commercially available soaps. This saves costs and also protects against cross-contamination. The soaps and disinfectants recommended by Benkiser can be viewed here.

The Primus stainless steel fitting is suitable for the soap dispenser.
